Product Detail

Model No.: HBE-70M

Production Capacity: 5000tons/Month

Delivery Date: 15days

Length: wire rolling

Weight: 5kg 15kg

Standard: GB/T10045 E500T-1 AWS ...

Means of Transport: Ocean,

Packing: 15KG&12.5KG

Brand Name: Haobnag

Type: mild& Low-alloy steel

COLOR: SILVER & BAKED

Material: Carbon Steels

HBE-70M is the wire for alkalinity steel welding . Excellent welding craft, smooth arc with low spatter and high deposition rates.

HBE-70M Mild & Low Alloy Steel Welding Wires for shipbuliding

GB/T10045E500T-1AWS A5.28 E70C-G

Features:HBE-70M is thewire for alkalinity steel welding . Excellent welding craft, smooth arc with low spatter and high depositionrates.

Applications:To be used for flat welding & fillet welding position weld with singer or double wire It has high depositionrates to be wide usedfor shipbuilding ,bridge and steel structure.

Notes:1). To take CO gas as gas-shielded and its purity should be up to 99.8% with flow at 20-25L/min.

2). Keep the electrode extension between 15-25mm.

3). Recommended current (DCEP)Wire to beincontact with positive pole.

4). Please clean the appearance of base metal before welding.

5). Use the wire under the best possible condition. It should be used up as soon as possible when unpacked.

Typical all Weld Metal Composition (%)

TRADE NAME	ITEM	C	Mn	Si	S	P
HBE-70M	Standard	≤0.18	≤1.75	≤0.90	≤0.03	≤0.03
HBE-70M	Test	0.05	1.16	0.35	0.005	0.017

Typical Properties of Deposited Metal

TRADE NAME	ITEM	Rm(MPa)	Rel(MPa)	A(%)	Akv(-20℃)(J)
HBE-70M	Standard	≥480	≥400	≥22	≥27
HBE-70M	Test	555	460	31	130

Welding Parameter Suggestions

Wire Diameter (mm)		F1.2	F1.4	F1.6
Current Range(A)	Flat Welding position	120~300	150~380	180~400
Current Range(A)	Fillet welding position	120~280	150~320	180~380
